Ex db IIC, Ex eb IIC, Ex ta IIIC, Ex nR IIC
COMPRESSION GLAND for cables using Braid or Copper Tape screening: VSD or VFD cable

• For indoors, outdoors, Group II, III, Zone 1, 2, 20, 21 and 22 hazardous areas.
• Passes the IECEx / UKEX / ATEX 100% pull test, so no additional cable clamping is required.
• EMC compliance enhanced by an integral and automatic 360°earth connection to the cable braid or copper tape screening.
• Braid can be cut to length and automatically earthed in the gland only or left uncut and earthed in the gland and the enclosure.
• Certified for use with all Ex Protection concepts.
• Instantly mixed and injected VORTEx® resin forms a 100% barrier seal around the individual elements of the cable and also the braid if it is left uncut.
• The VORTEx® resin seals around the elements of the cable and can prevent explosive gases or liquids from passing down the cable. An elastomeric seal grips the cable sheath giving superior cable retention and IP rating.
• Precision manufactured from high-quality brass (Marine Grade Electroless Nickel Plated™) available in aluminium or stainless steel 316/316L on request.
• Supplied with a captive thread-sealing gasket (parallel threads only)
